Eaton PLSM-C32/3N-MW circuit breaker
The Eaton PLSM-C32/3N-MW miniature circuit breaker belongs to the xPole series and offers reliable protection for three-phase circuits with neutral conductor at a rated current of 32 A. It is designed for residential and commercial buildings and complies with IEC/EN 60898-1.
With its C-curve tripping characteristic, this device is suitable for circuits with inductive loads. These include high-power motors, compressors, and transformers. The C-curve tolerates higher inrush currents than the B-curve. Consequently, false tripping is avoided with inductive loads exhibiting high starting currents.
The four-pole design with simultaneous neutral connection disconnects all four conductors simultaneously in the event of a fault. This ensures complete galvanic isolation. Therefore, your circuit is completely de-energized and safe for maintenance work.
Mounting on the DIN rail is straightforward. You can connect solid and stranded conductors from 1 mm² to 25 mm². Auxiliary switches and other accessories can also be retrofitted.
The rated breaking capacity is 10 kA. Furthermore, the operating voltage is up to 400 V AC. The insulation voltage is 440 V and the surge voltage withstand capability is 4 kV. The device also complies with energy limiting class 3 and is RoHS compliant.
Technical specifications at a glance
-
Model code: PLSM-C32/3N-MW
-
Article number: 242546
-
EAN: 4015082425463
-
Number of poles: 3-pole + N
-
Trigger characteristic: C
-
Rated current: 32 A
-
Rated breaking capacity: 10 kA (IEC/EN 60898-1)
-
Rated operating voltage: 400 V AC
-
Rated insulation voltage: 440 V
-
Impulse voltage withstand: 4 kV
-
Frequency: 50/60 Hz
-
Protection rating: IP20
-
Width: 4 TE (70 mm)
-
Connection cross-section (solid wire): 1 – 25 mm²
-
Connection cross-section (multi-stranded): 1 – 25 mm²
-
Energy limiting class: 3
-
Weight: 0.454 kg
-
Certifications: IEC/EN 60898-1, RoHS compliant
For high-performance three-phase circuits with neutral conductors and inductive loads, the Eaton PLSM-C32/3N-MW circuit breaker is the ideal choice. Order now and protect your system professionally.
