Eaton PLSM-C32/3-MW circuit breaker
The Eaton PLSM-C32/3-MW miniature circuit breaker belongs to the xPole series and protects three-phase circuits with a rated current of 32 A. It is designed for residential and commercial buildings and complies with the IEC/EN 60898-1 standard.
With its C-curve tripping characteristic, this device is optimized for inductive loads. These include motors, compressors, and transformers. The C-curve tolerates higher inrush currents than the B-curve. Therefore, false tripping does not occur with high-power inductive loads.
Installation on the DIN rail is quick and easy. Solid and stranded conductors from 1 mm² to 25 mm² can be connected. All three poles switch simultaneously, ensuring the three-phase circuit is fully protected.
The rated breaking capacity is 10 kA. Additionally, the operating voltage is up to 400 V AC. The insulation voltage is 440 V, and the impulse voltage withstand capability is 4 kV. Furthermore, the device complies with energy limiting class 3.
The 3 TE width allows for space-saving installation. Furthermore, the device is RoHS compliant and the IP20 protection rating ensures protection against accidental contact.
Technical specifications at a glance
-
Model code: PLSM-C32/3-MW
-
Article number: 242477
-
EAN: 4015082424770
-
Number of poles: 3-pole
-
Trigger characteristic: C
-
Rated current: 32 A
-
Rated breaking capacity: 10 kA (IEC/EN 60898-1)
-
Rated operating voltage: 400 V AC
-
Rated insulation voltage: 440 V
-
Impulse voltage withstand: 4 kV
-
Frequency: 50/60 Hz
-
Protection rating: IP20
-
Width: 3 TE (52.5 mm)
-
Connection cross-section (solid wire): 1 – 25 mm²
-
Connection cross-section (multi-stranded): 1 – 25 mm²
-
Energy limiting class: 3
-
Weight: 0.356 kg
-
Certifications: IEC/EN 60898-1, RoHS compliant
The Eaton PLSM-C32/3-MW circuit breaker is ideal for high-power three-phase circuits with inductive loads. Order now and benefit from Eaton quality.
