Hager miniature circuit breaker, characteristic curve C, 3-pole, 10A, QC - MCS310

Hager MCS310 miniature circuit breaker – characteristic curve C, 3-pole, 10A, QC

The Hager MCS310 miniature circuit breaker is a first-class choice for the reliable protection of your electrical installations. With a rated current of 10 A and a robust C-curve tripping characteristic, this 3-pole circuit breaker is particularly well-suited for use in industrial and commercial applications. The integrated Quick Connect (QC) technology enables fast and easy installation, making the MCS310 ideal for modern electrical installations.

Technical details:

• Manufacturer : Hager

• Model : MCS310

• Product type : Miniature circuit breaker (MCB)

• Number of poles : 3 – protects three live conductors, ideal for three-phase systems
• Rated current (In) : 10 A – suitable for medium current loads

• Switching capacity : 6 kA – ensures high short-circuit withstand capability and protection against electrical disturbances

• Tripping characteristic : Characteristic curve C – trips at 5–10 times the rated current, optimal for inductive loads such as motors and transformers

• Power supply : 400 V AC – suitable for three-phase AC networks

• Mounting type : DIN rail – enables simple and space-saving installation in the distribution box

• Operating temperature range : -25°C to +70°C – ensures reliable operation under various environmental conditions

• Protection class : IP20 – protects against contact and solid foreign objects, suitable for dry indoor areas

• Quick Connect (QC) function : simplifies wiring and significantly reduces installation effort.


Advantages of the Hager MCS310:

1. Reliable protection : The MCS310 provides comprehensive protection for your electrical systems. With its C-curve characteristic, it is ideal for use with inductive loads, as it reliably trips at high inrush currents and minimizes false alarms.

2. High short-circuit withstand capability : With a breaking capacity of 6 kA, this circuit breaker effectively protects against short circuits and ensures that your devices and systems can be operated safely.

3. Easy installation thanks to QC function : The Quick Connect technology enables fast and uncomplicated wiring, which significantly reduces installation effort and saves time.

4. Versatile applicability : The Hager MCS310 is ideally suited for various applications, including the protection of motors, transformers and other electrical equipment in industrial and commercial environments.


Conclusion:

The Hager MCS310 miniature circuit breaker is the ideal solution for anyone seeking safe, efficient, and user-friendly protection for their electrical installations. With its outstanding technical features and practical Quick Connect function, it meets the requirements of modern electrical installations and ensures reliable operation. Trust the Hager MCS310 and protect your electrical systems effectively!

Manufacturer part number : MCS310
Article number : VER0159
